649 cc DOHC Parallel Twin-cylinder Engine

• Under-engine muffler with 3-way catalyzer aids mass centralization for light handling and great looks
• Oil jets on the connecting rod ends spray oil on the undersides of the pistons to aid cooling
• 180 degree crankshaft and a balancer shaft produce a remarkably smooth engine
• Tuned to deliver smooth, responsive power in the low to mid-rpm range for exceptional roll-on response ideal for negotiating city traffic, tight backroads and anything in between
• Narrow, chrome composite-plated aluminum cylinders help reduce engine width
• Semi-dry sump oil system reduces overall engine height
• Triangular crank and transmission shaft layout keeps it short front to back
• Most compact engine in its category helps reduce the dimensions of the entire motorcycle

6-speed Transmission

• Versys’ racing-style cassette transmission uses a compact layout that’s easily removable as a single unit from the engine cases for much easier gearbox maintenance

6-spoke Wheels

• Lighter wheels increase overall performance – suspension, handling, acceleration / deceleration and initial turn-in
• Like the ones you’ll find on the Ninja ZX™-6R and ZX-10R, these 6-spoke wheels use less material between spokes so rim thickness is reduced along with overall wheel weight

Adjustable Long-travel Front Fork

• Fork height, spring preload and rebound damping can be adjusted to fine-tune the suspension to specific conditions, riding styles and loads
• Tapered, relatively short outer tubes help provide the ideal stiffness balance to complement frame stiffness and chassis settings
• A long-travel 41 mm inverted fork delivers excellent performance over a wide range of conditions

Digital Fuel Injection (DFI®)

• Precise fuel injection provides great fuel mileage, and the 3-way catalyzer significantly reduces emissions
• An automatic fast idle system makes starting and warm-up easy, even on cold days
• Sub-throttles, located behind the main throttle valves, give the Versys precise throttle response and great feel as well
• A pair of 38 mm Keihin throttle bodies with ECU-controlled sub-throttle valves mean optimum performance and rideability

Key Features

• Aggressive styling gives the Versys a distinctive look
• Under-engine exhaust promotes better weight centralization
• Aluminum swingarm and 17 inch cast aluminum wheels reduce unsprung weight for better ride quality
• 3-way adjustable windscreen allows customizable wind protection
• Adjustable single-shock rear suspension offers progressive damping as suspension load increases
• Long-travel fork delivers excellent performance over a wide range of situations
• 649 cc parallel twin with digital fuel injection (DFI®) provides smooth, responsive power
• Amazingly versatile motorcycle is exceptionally comfortable to ride in a variety of situations, from commuting, to backroads, to touring and even track days
• New ABS brakes offer excellent performance and enhanced confidence in adverse conditions

Liquid-cooling

• Coolant routed through the engine cases reduces the number of external hoses
• Closer engine tolerances mean more horsepower
• Engine temperatures stay consistent for long engine life and sustained power in tough conditions

New Anti-lock Disc Brakes

• Same rotor design as found on the Ninja® supersport machines; petal design rotors offer improved cooling and warp resistance compared to traditional discs
• Dual 300 mm petal-style rotors with 2-piston calipers in front and a single 220 mm petal rotor with a single-piston caliper in back provide plenty of stopping power
• New ABS brakes offer excellent performance and enhanced confidence in adverse conditions

Single Shock Rear Suspension

• The Showa shock has adjustable preload and rebound damping, and uses a free piston and 2-stage damping valves for smooth action during initial compression that becomes firmer near the end of the stroke for a more planted feel
• The short, compact frame and engine design allow the swingarm to be longer, which improves overall handling
• A distinctive aluminum gull-wing swingarm controlled by a lay-down single shock complements the distinctive frame design, with an integrated line flowing from steering head to rear hub

Slender Trellis Frame

• 3D computer analysis in the design process achieved optimum stiffness balance for superior ride and handling
• Versys’ exotic-looking trellis frame is small, light and narrow at the knees and pegs for excellent comfort and control

Unique Bodywork

• The windscreen provides a large still-air pocket for comfort, and its 3-position adjustability makes it adaptable to fit a variety of riders and climates
• The fairing, stacked dual headlight, front fender and mirrors, and a Z1000-style LED tail light give the Versys a distinctly bold and high-tech appearance

Very Comfortable Ergonomics

• Rubber bushings at the rear engine mounts and hollow rubber-covered footpegs result in reduced engine vibration and a more comfortable ride
• Grab rails, seat cover material, and a comfortable seating position make the Versys more fun and less stressful for passengers
• An easy-to-read instrument panel has a large analog tachometer and digital readout for the speedometer, fuel gauge, odometer, dual trip meters and clock. White LED backlighting provides increased visibility at night.
• Each section of the 2-piece seat was designed with a different thickness and firmness of foam to optimize comfort for both rider and passenger
